Factory direct sales,Support Wholesale, support OEM
OEM: You can customize your logo the startup screen. Wholesale more than 50 pieces customized
If you need customization, please contact me.
Whatsapp: +86 137 9825 0203
Email: sales09@autopvision.com

VGA to USB Capture Converter USB3.0 HD Audio and Video Capture Device Driver Free Support Plug and Play Game Live Streaming Box

About VGA Capture:
VGA Capture 1080P is an audio and video capture devicewhich support VGA input and USB output. It is support UVC/UAC standard, transport port is USB 2.0(loop out version is USB 3.0),it compatible with Android, Windows and Linux system. It is a driver free HD capture device also support Plug and Play.

Features:
VGA capture convert VGA signal to USB signal from PC,  PSP,industrial camera microscopes,medical devices, it capture the VGA signal and recording by PC, notebook,  cell phone. The device support audio input too. This capture card is always use in medical, video meeting, live stream for game, education. It compatible software such as OBS, POTPLAYER,AMCAP,VLC and so on,  and also support USB camera in Android system.
How to use:
1,Connect VGA signal source to VGA INPUT port. (Resolution only same as in spec. sheet)
2,Connect USB OUTPUT port to computer USB via USB cable.(Driver Free)
3,A separate microphone connect to MIC IN if necessary.
4,Loop out version support VGA out connect to monitor.
5,Running capture software on computer, select  device "ANF_Cap Video" and activate it. Red LED light flashing means signal captured.
Sweet tips:
Because of mini size designed, it is normal if the
device is hot in working mode.

Loop out version:

Input :VGA,3.5mm connector

Output:USB 3.0

Standard: USB2.0,loop out

Video output resolution:

1920*1080 , 1600*1200 ,

1360*768 , 1280*1024 ,

1280*960 , 1280*720 ,

1024*768 , 800*600 ,

720*480,720*576,640*480

Frame: 5-60 frame adjustable

Standard UVC/UAC Driver Free

Operation system: Windows/Linux /Android/MAC

Capture software:OBS/Potplayer(Windows)/USB camera(Android)

Consumption :＜1.5Wat

Working Temp.

Workng Hum.:5%-90%

Size :82mm*63mm*21mm

Weight: 100
